Nissan Murano: Headlight and turn signal switch / Instrument brightness control

LED Daytime Running Lights (DRL) system

The LED portion of the headlights automatically illuminate at 100% intensity when the engine is started with the parking brake released. The LED DRL operate with the headlight switch in the OFF position or in the position...

Turn signal switch

Move the lever up or down to signal the turning direction. When the turn is completed, the turn signal cancels automatically. Lane change signal Move the lever up or down until the turn signal begins to flash, but the lever does not latch, to signal a lane change...
