DTC Description
DTC DETECTION LOGIC DTC No.
CONSULT screen items
(Trouble diagnosis content) DTC detection condition
C1A34–64
COMMAND ERROR
(Command error)
Diagnosis condition
When MAIN switch of ICC system is ON
When driving the Nissan Murano vehicle
Signal (terminal)
CAN communication signal
Threshold
If an error occurs in the command signal that ADAS control unit transmits to ECM via CAN communication
Diagnosis delay time
1 second or less
POSSIBLE CAUSEADAS control unitFAIL-SAFEThe following systems are canceled:
Vehicle-to-vehicle distance control mode
Conventional (fixed speed) cruise control mode
Automatic Emergency Braking (AEB)
Automatic Emergency Braking (AEB) with pedestrian detection
Intelligent Forward Collision Warning (I-FCW)
Confirmation Procedure
CHECK DTC PRIORITY
If DTC “C1A34–64” is displayed with DTC “U1000–01”, first diagnose the DTC “U1000–01”...
DTC Description
NOTE:
The Signal Tech II Tool [– (J-50190)] can be used to perform the following functions: Refer to the Signal Tech II User Guide for additional information.
Activate and display TPMS sensor IDs
Display tire pressure reported by the TPMS sensor
Read TPMS DTCs
Register TPMS sensor IDs
DTC DETECTION LOGIC DTC No...
