Nissan Murano: System / Automatic Drive Positioner System
SYSTEM DIAGRAM
OUTLINE
The system automatically moves the driver seat, steering column and door mirror position by the driver seat control unit and the automatic drive positioner control unit. The driver seat control unit corresponds with the automatic drive positioner control unit by UART communication.
| Function | Description | |
|---|---|---|
| Manual function | The driving position (seat, steering column and door mirror position) can be adjusted by using the power seat switch LH, ADP steering switch or door mirror remote control switch. | |
| Memory function | The seat, steering column and door mirror move to the stored driving position by pressing seat memory switch (1 or 2). | |
| Entry/Exit assist function | Exit | On exit, the seat moves backward and the steering column moves upward. |
| Entry | On entry, the seat and steering column return from exiting position to the previous driving position. | |
| Intelligent Key interlock function | Performs memory operation, exiting operation and entry operation by Intelligent Key unlock operation or driver side door request switch unlock operation. | |
NOTE:
The lumbar support system is controlled independently with no link to the automatic drive positioner system.
System
..
Manual Function
System Description
SYSTEM DIAGRAMDESCRIPTIONThe driving position (seat, steering column and door mirror position) can be adjusted manually with power seat switch LH, ADP steering switch and door mirror remote control switch...
