Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collisions...
Other information:
Removal and Installation
REMOVALDischarge the refrigerant. Refer to Recycle Refrigerant.
Partially remove the front edge of the front fender protector (RH). Refer to Removal and Installation.
Remove the bolts that retain the oil cooler line brackets to the engine block and reposition the oil cooler line aside...
Diagnosis Procedure
CHECK CONNECTOR
Turn the ignition switch OFF.
Disconnect the battery cable from the negative terminal.
Check the following terminals and connectors for damage, bend and loose connection (unit side and connector side).
Around view monitor control unit
ADAS control unit
Is the inspection result normal?
YES>>
GO TO 2...
